3kw-50kw Hybrid Inverter for Solar Energy Storage System

Hybrid Inverter

An on-grid inverter’s main job is to convert DC power generated from the PV array into usable AC power. Hybrid inverters go a step further and work with batteries to store excess power as well. In the developing world, hybrid inverters are more of a necessity to compensate for weak or intermittent grids or a lack of grid electricity all together.

Deye hybrid inverters include single phase 3-16kW and three-phase 8-12kW, For the SUN-3K-SG04LP1-24-EU, it uses 24V battery bank and the rest of them adopts 48V battery. Also, the SUN-16K-SG01LP1-EU is the max single phase hybrid inverter on the global market.

The Grid-interactive inverter consists of several hardware elements. The Grid-interactive inverter controls and monitors the connection of the electricity from the power plants. In addition, it also controls the disconnection of excess power from the plants. It ensures the dispatch of power at the peak time based on demand.



Deye SUN-3/3.6/5/6K-SG04LP1 | 3-6kW | Single Phase | 2 MPPT | Hybrid Inverter | Low Voltage Battery

Higher yields / Safe & Reliable / Smart / User-friendly

SUN 3/6K-SG04，hybrid inverter, is suitable for residential and light commercial use, maximizing self-consumption rate of solar energy and increasing your energy impendence.   During the day, the PV system generates electricity which will be provided to the loads initially. Then, the excess energy will charge the battery via SUN 3/6K-SG04. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout.

It equipped with RS485/CAN port for battery communication.

The New SUN-3K-SG04LP1 hybrid inverter adopts 24V battery, greatly improving your system safety.

Features：

• Colorful touch LCD, IP65 protection degree

• AC couple to retrofifit existing solar system

• Max. 16 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel

• Max. charging/discharging current of 140A

• 6 time periods for battery charging/discharging

• Support storing energy from diesel generator

Parameters：

SUN-3.6/5/6K-SG03LP1-EU | 3.6-6kW | Single Phase | 2 MPPT | Hybrid Inverter | Low Voltage Battery

Higher yields / Safe & Reliable / Smart / User-friendly

SUN 3.6/6K-SG，hybrid inverter, is suitable for residential and light commercial use, maximizing self-consumption rate of solar energy and increasing your energy impendence.   During the day, the PV system generates electricity which will be provided to the loads initially. Then, the excess energy will charge the battery via SUN 3.6/6K-SG. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout.

It equipped with RS485/CAN port for battery communication.

Features：

• Colorful touch LCD, IP65 protection degree

• AC couple to retrofifit existing solar system

• Max. 16 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel

• Max. charging/discharging current of 135A

• 6 time periods for battery charging/discharging

• Support storing energy from diesel generator

Parameters：

SUN-3.6/5/6/7.6/8K-SG05LP1-EU | 3.6-8kW | Single Phase | 2 MPPT | Hybrid Inverter | Low Voltage Battery

Higher yields / Safe & Reliable / Smart / User-friendly

SUN 3.6/8K-SG05，hybrid inverter, is suitable for residential and light commercial use, maximizing self-consumption rate of solar energy and increasing your energy impendence.   During the day, the PV system generates electricity which will be provided to the loads initially. Then, the excess energy will charge the battery via SUN 3.6/8K-SG05. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout.

It equipped with RS485/CAN port for battery communication

Features：

• Colorful touch LCD, IP65 protection degree

• AC couple to retrofifit existing solar system

• Max. 16 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel

• Max. charging/discharging current of 190A

• 6 time periods for battery charging/discharging

• Support storing energy from diesel generator

Parameters：

SUN-5/6K-SG01LP1-US SUN-7.6/8K-SG01LP1-US/EU | 5-8kW | Single Phase | 2 MPPT | Hybrid Inverter | Low Voltage Battery

Higher yields / Safe & Reliable / Smart / User-friendly

The series, SUN-5/6K-SG01LP1-US SUN-7.6/8K-SG01LP1-US/EU, is a single-phase low voltage (48V) hybrid inverter that enables enhanced energy independence and maximizes self-consumption through export limit feature and “time of use” function. With the frequency droop control algorithm, this series product supports single phase and three phase parallel application, and the Max. parallel units is up to 16pcs.



Features：

• Colorful touch LCD, IP65 protection degree

• 6 time periods for battery charging/discharging

• Max. charging/discharging current of 190A

• AC couple to retrofit existing solar system

• Support storing energy from diesel generator

• Max. 16 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel

Parameters：

SUN-5/6/8/10/12K-SG04LP3 | 5-12kW | Three Phase | 2 MPPT | Hybrid Inverter | Low Voltage Battery

Higher yields / Safe & Reliable / Smart / User-friendly

SUN 5/6/8/10/12K-SG is brand new three phase hybrid inverter with low battery voltage 48V, ensuring system safe and reliable. With compact design and high-power density, this series supports 1.3 DC/AC ratio, saving device investment. It supports three phase unbalanced output, extending the application scenarios. Equipped with CAN port (x2) BMS and parallel, x1 RS485 port for BMS, x1 RS232 port for remotely control, x1 DRM port, which makes the system smart and flexible.

Features：

• 100% unbalanced output, each phase; Max. output up to 50% rated power

• AC couple to retrofifit existing solar system

• Max. 10 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel

• Max. charging/discharging current of 240A

• Support storing energy from diesel generator

• 48V low voltage battery, transformer isolation design

• 6 time periods for battery charging/discharging

Parameters：

SUN-12/14/16K-SG01LP1 | 12-16kW | Single Phase | 3 MPPT | Hybrid Inverter

Higher yields / Safe & Reliable / Smart / User-friendly

SUN 12/14/16K-SG，hybrid inverter, is suitable for residential and light commercial use, maximizing self-consumption rate of solar energy and increasing your energy impendence.   During the day, the PV system generates electricity which will be provided to the loads initially. Then, the excess energy will charge the battery via SUN 12/14/16K-SG. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout.

It equipped with RS485/CAN port for battery communication

• Colorful touch LCD, IP65 protection degree

• 6 time periods for battery charging/discharging

• Max. charging/discharging current of 290A

• Support storing energy from diesel generator

• AC couple to retrofifit existing solar system

• Max. 16 pcs parallel for on-grid and off-grid

• operation; Support multiple batteries parallel

Parameters：

SUN-5/6/8/10/12/15/20/25K-SG01HP3-EU-AM2 | 5-25kW | Three Phase | 2 MPPT | Hybrid Inverter | High Voltage Battery

Higher yields / Safe & Reliable / Smart / User-friendly

SUN 5/6/8/10/12/15/20/25K-SG01HP3-EU-AM2 is brand new three phase hybrid inverter with High voltage battery 160-700V, ensuring system efficiency and less heat dissipation. With compact design and high-power density, this series supports 1.3 DC/AC ratio, saving device investment. It supports three phase unbalanced output, extending the application scenarios.

Features：

• 100% unbalanced output, each phase

• AC couple to retrofifit existing solar system

• *Max. 10 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel

• Max. charging/discharging current of 50A

• High voltage battery, higher effificiency

• 6 time periods for battery charging/discharging

• Support storing energy from diesel generator

Parameters：

SUN-29.9/30/35/40/50K-SG01HP3-EU-BM2/3/4 | 29.9-50kW | Three Phase | 2/3/4 MPPT | Hybrid Inverter | High Voltage Battery

Higher yields / Safe & Reliable / Smart / User-friendly

SUN-29.9/30/35/40/50K-SG01HP3-EU-BM2/3/4 is brand new three phase hybrid inverter with High voltage battery 160-800V, ensuring system efficiency and less heat dissipation. With compact design and high-power density, this series supports 1.3 DC/AC ratio, saving device investment. It supports three phase unbalanced output, extending the application scenarios.

Features：



• 100% unbalanced output；each phase

• AC couple to retrofifit existing solar system

• *Max. 10 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel

• Max. charging/discharging current of 100A

• High voltage battery, higher efficiency

• 6 time periods for battery charging/discharging

• Support storing energy from diesel generator

Parameters：
