Product Details:
|
| Nominal Capacity: | 200Ah | Nominal Voltage: | 12V |
|---|---|---|---|
| Internal Impedence: | / | Operating Votage: | / |
| Dimension: | 280mm*276mm*180mm | Battery Weight: | 23.5kg±0.5kg |
12V 200Ah Sinopoly LiFePO4 Battery Module
Sinopoly Battery has developed a range of lithium-ion batteries with different specifications and characteristics to meet the needs of different industries and applications. The company's batteries are known for their high energy density, long cycle life, and excellent safety performance. Sinopoly Battery also offers custom battery solutions for customers with specific requirements.
we provide 12V200AH LiFePO4 battery pack with 4 200AH Sinopoly Battery cells in series,they are packaged by jigs. The total weight is around 14.5kg. We connected by our connectors. they are widely used in auto audio system.
Parameters:
Item | specification | |
Product Model | SP-LFP-200AHA(A) | |
Nominal Capacity | 200Ah | |
Nominal Voltage | 3.2V | |
Weight | 5.8Kg±0.2Kg | |
Internal Impedance | ≤0.4mΩ | |
Cycle Life | ≥2000Times | |
Self-discharge rate | ≤5% | |
Dimension | Height | 280±1mm |
Width | 180±1mm | |
Thickness | 69±0.5mm | |
Charge | Standard Current | 66A |
Max. Current | 400A | |
Limited Voltage | 3.65V | |
Discharge | Cut-off Current | 6.7A |
Standard Current | 66A | |
Max. Current | 600A | |
Cut-off Voltage | 2.5V | |
Operation Temperature | Charge | 0℃~45℃ |
Discharge | -20℃~55℃ | |
Storage Temperature | -10℃~45℃ | |
Storage Humidity | 25%~85% | |
Details:
Sinopoly Battery SP-LFP100AHA 3.2V 100Ah Lifepo4 Battery Cells
