Product Details:
|
| Nominal Capacity: | 21.7Ah | Nominal Voltage: | 3.2V |
|---|---|---|---|
| Internal Impedence: | / | Operating Votage: | / |
| Dimension: | 224mm*90.25mm*9.8mm | Battery Weight: | 0.39±0.05 kg |
Lifepo4 battery can be used in a variety of fields, including mobile phones, tablets, laptops, smart wear, mobile power, game consoles, action cameras, electronic cigarettes, wireless speakers, drones, AR/VR and other fields.
Advantages：
Pouch battery cell offer several advantages that contribute to their widespread use in various electronic devices.
· The flexible and lightweight design of pouch batteries allows for greater form factor versatility, allowing manufacturers to integrate them into slimmer, more compact devices.
· Soft-pack batteries generally exhibit higher energy density and can provide more power in smaller packages. This means longer battery life and better overall performance for electronics.
· Soft-pack batteries tend to dissipate heat more efficiently, so the absence of a rigid casing also enhances thermal management.
· The manufacturing process for pouch batteries is generally simpler and more cost-effective, making them an economically viable option.
Parameters：
Item | Specification |
Nominal Voltage | 3.2V |
Capacity | ≥21.7Ah |
Weight Energy Density (Wh/kg) | 178 |
Operating Voltage Range | 2.5-3.65V |
Output Voltage | 3.275~3.300V |
Charge Mode | CC/CV |
Maximum Continuous Charging Current | 1C,21.7A |
Standard Discharge Current | 0.2C,4.4A |
Maximum Continuous Discharge Current | 1C,21.7A |
ACIR | ≤1.8mΩ |
Operating Temperature Range (Charging) | -20~60℃ |
Operating Temperature Range (Discharge) | -20~60℃ |
Weight | 0.39±0.05 kg |
Size | 224mm*90.25mm*9.8mm |
Details：
